Press Brake machines help you optimize your production
What is a press brake?
Press brake is a machine used for bending sheet metal and metal plates, most commonly sheet metal. It forms predetermined bends by clamping the workpiece between a matching top tool and bottom die.
Our press brakes range in size from 3.7 tons to 22 tons (in tandem), and they come in a variety of configurations from 2 to 11 axes.
Hisman hydraulic CNC press brake machines can be fully configured to meet customer requirements and are designed for increased power, productivity and versatility. Our machines' robust construction and advanced technology ensure reliable operation and perfect repeatability, bending materials from soft brass to chrome molybdenum.
Hisman press brakes can handle diverse demands, increasing productivity while maintaining unwavering reliability. The precision provided by our press brakes is a testament to our commitment to innovation and superior craftsmanship. We provide industry-leading service and support for each of our press brakes.
Hisman is able to handle diverse needs, increasing productivity while maintaining unwavering reliability. The precision provided by our press brake machines is a testament to our commitment to innovation and superior craftsmanship.
Specification
| Model | XSM 50/1500 | XSM 80/2500 | XSM 250/3200 | XSM 320/3200 | XSM 400/3200 | XSM 250/4000 | XSM 320/4000 | XSM 400/4000 | XSM 110/3200 | XSM 130/3200 | XSM 170/3200 | XSM 220/3200 | XSM 110/4000 | XSM 130/4000 | XSM 170/4000 | XSM 220/4000 |
| Nominal Pressure | 500KN | 800KN | 2500KN | 3200KN | 4000KN | 2500KN | 3200KN | 4000KN | 1100KN | 1300KN | 1700KN | 2200KN | 1100KN | 1300KN | 1700KN | 2200KN |
| Workbench Length | 1500mm | 2500mm | 3200mm | 3200mm | 3200mm | 4000mm | 4000mm | 4000mm | 3200mm | 3200mm | 3200mm | 3200mm | 4000mm | 4000mm | 4000mm | 4000mm |
| Column Spacing | 1200mm | 2100mm | 2700mm | 2600mm | 2600mm | 3300mm | 3200mm | 3200mm | 2700mm | 2700mm | 2700mm | 2700mm | 3300mm | 3300mm | 3300mm | 3300mm |
| Slide Stroke | 165mm | 165mm | 250mm | 250mm | 300mm | 250mm | 250mm | 300mm | 205mm | 205mm | 205mm | 205mm | 205mm | 205mm | 205mm | 205mm |
| Maximum Opening Height | 420mm | 420mm | 520mm | 520mm | 540mm | 520mm | 520mm | 540mm | 460mm | 460mm | 460mm | 460mm | 460mm | 460mm | 460mm | 460mm |
| Throat Depth | 250mm | 250mm | 405mm | 405mm | 405mm | 405mm | 405mm | 405mm | 400mm | 400mm | 400mm | 400mm | 400mm | 400mm | 400mm | 400mm |
| Workbench Height | 850mm | 930mm | 900mm | 900mm | 900mm | 900mm | 900mm | 900mm | 930mm | 930mm | 930mm | 930mm | 930mm | 930mm | 930mm | 930mm |
| Quick Down Speed | 250mm/s | 230mm/s | 140mm/s | 130mm/s | 120mm/s | 140mm/s | 130mm/s | 120mm/s | 220mm/s | 200mm/s | 180mm/s | 180mm/s | 220mm/s | 200mm/s | 180mm/s | 180mm/s |
| Slow Down Speed | 10mm/s | 10mm/s | 8mm/s | 8mm/s | 7mm/s | 8mm/s | 8mm/s | 7mm/s | 10mm/s | 10mm/s | 10mm/s | 10mm/s | 10mm/s | 10mm/s | 10mm/s | 10mm/s |
| Return Speed | 200mm/s | 180mm/s | 100mm/s | 100mm/s | 90mm/s | 100mm/s | 100mm/s | 90mm/s | 160mm/s | 160mm/s | 130mm/s | 130mm/s | 160mm/s | 160mm/s | 130mm/s | 130mm/s |
| Main Motor Power | 5.5kw | 7.5kw | 18.5kw | 22kw | 30kw | 18.5kw | 22kw | 30kw | 7.5kw | 11kw | 11kw | 18.5kw | 7.5kw | 11kw | 11kw | 18.5kw |
| Fuel Tank Volume (liters) | 180L | 280L | 450L | 500L | 650L | 450L | 500L | 650L | 300L | 300L | 400L | 400L | 350L | 350L | 450L | 450L |
| Rear Stopper X-axis Travel | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm |
Overall Dimensions
(Length*Width*Height) | 1750*1350*2200mm | 2800*1400*2500mm | 3560*1850*2900mm | 3560*1850*2950mm | 3560*2100*3200mm | 4360*1850*2900mm | 4360*1850*2950mm | 4360*2100*3200mm | 3550*1650*2600mm | 3550*1700*2600mm | 3560*1700*2800mm | 3600*1700*2800mm | 4300*1650*2600mm | 4300*1700*2600mm | 4300*1700*2800mm | 4300*1700*2800mm |
| Machine Weight | 3.7T | 5.8T | 16.5T | 17.6T | 20.5T | 18T | 19.6T | 22T | 7.8T | 8.6T | 10.8T | 11.5T | 8.8T | 9.5T | 11.5T | 12.8T |
Press brake applications:
Since press brake machines can be fitted with a wide range of punches and dies, they can be used for almost any sheet or plate metal shaping application. The most common are:
Automotive panels
Airframes
Metal artwork
Furniture
Metal containers
Many other sheet metal forming applications
Almost any sheet or plate metal bending application can be accomplished using a press brake. Press brakes are most often used to produce multiple pieces of the same workpiece for further processing.
Why Choose Hisman Press Brake Machine?
Innovative modular design:
Our hydraulic press brake machines can also be combined with automation modules to create a complete hydraulic system for the entire work process, further increasing the machine's versatility.
From basic to high-end machines, customized solutions are available at affordable prices. Check out our press brake machines for sale to learn more about configurations and technical parameters.
Experience:
Professional R&D team dedicated to researching cutting-edge technology for customer press brake machines.
A wider variety of press brake solutions:
Comprehensive stock of basic tools and solutions modified to customer needs
Hisman high-quality equipment:
The key components of Hisman bending machines are manufactured in Germany.
After-sales service and support:
Original Hisman spare parts guarantee full performance and long-term durability. Extensive consulting services for machine operation, programming and maintenance.
